Gunmetal Flange
| Business Type | Manufacturer, Exporter, Supplier, Importer |
| Type | Gunmetal Flanges |
| Material | Gun Metal |
| Shape | Round, As Per Drawing |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
We are manufacturing Gunmetal Flanges as per various sizes and specification and customizing to the appropriate needs from Customers. Gunmetal Flange is mechanically designed to fit into pipes of different circumference and radius. It is uniquely designed to suit the manufacturing requirements of petro-chemical and chemical industries. It is used in applications like Pumps, Valves. Vessels in manufacturing & Food Processing, in pipe connections of Industrial waterworks, heat exchangers & heating systems of all sizes. The following table depicts the chemical composition of various grades of Gunmetal Flanges manufactured by us: -
|
Constituents |
Percentage Composition |
||
|
|
Grade -1 |
Grade - 2 |
Grade - 3 |
|
Tin |
4.0-6.0 |
6.0-8.0 |
9.5-10.5 |
|
Zinc |
4.0-6.0 |
1.5-3.0 |
1.75-2.75 |
|
Lead |
4.0-6.0 |
2.5-5.5 |
0-1.5 |
|
Nickel |
2.0 Max |
2.0 Max |
1.0 Max |
|
Iron |
0.35 Max |
0.35 Max |
0.15 Max |
|
Aluminium |
0.01 Max |
0.01 Max |
------------- |
|
Total Impurities |
0.8 Max |
0.7 Max |
0.5 Max |
|
Copper |
Remainder |
Remainder |
Remainder |
