Aluminium Bronze Ingots And Castings

Aluminium Bronze Ingots And Castings

Price : 830.00 - 1,200.00 / Kilogram

MOQ : 300.00 Kilogram

Business Type	Manufacturer, Exporter, Supplier, Importer
Country of Origin	India
Size	20x3inch, 25x4inch, 30x5inch, 35x6inxh, 40x7inch, ASTM, BS, IS Specification
Type	Alloy of Copper with Aluminium, Iron & Nickel
Click to view more

Preferred Buyer From

Location

Worldwide

Product Details

Material

Bronze, Iron & Nickel

Shape

Rectengular, Square, Bush Bearing & Others As Per Drawings

Application

Construction, Household Repair, Nuclear Shielding, Etc.

Weight

1-100kg, 100-200kg, 200-300kg

Grade

ASTM, BS, BS:1400-AB-1 & BS:1400-AB-2.

Color

Golden, Shiny Yellowish Brown

Purity

Aluminium Bronze Alloy As Per Grades AB-1 & AB-2.

Condition

New

Surface Finishing

Non Polished, Polished

Chemical Composition

As Per IS:305-1961 & Grades AB-1, AB-2, NES 747.

Advantage

Components Used Handling Sea Water, Sour Mine Waters, Non Oxidizing Acids, Industrial Process Fluids

Suitable For

Applications Requiring Resistance To Corrosion.

Port

Kolkata Port

Payment Terms

L/C, D/A, D/P, T/T, Other

Delivery Time

As Per Order & Quantity of Manufacture

Packaging Details

They are packed in Gunny Bags & Enclosed In Wooden Crates & Cartoons after which they are Loaded Onto Containers, Carrier Vessels for Shipment By Road, Railways & Seas.

Aluminium Bronze Ingots & Castings manufactured by us are covered under the specification IS:305-1981 Or Reaffirmed 2006. Aluminium Bronze Ingots cast are of uniform quality and reasonably free from slag, dross and otherharmful contaminations. They are remelted for producing industrial castings. Castings of Aluminium Bronze are madefree from harmful inclusions and cracks. The ingots cast are generally 10Kg to 12 Kg Per Piece. The Castings areprepared as per dimensions and in accordance with the drawings. Aluminium Bronze Castings are used in marinehardware, shafts & pump and valve components for handling sea water, sour mine waters, nonoxidizing acids &industrial process fluids. They area also used in applications such as heavy-duty sleeve bearings and machine tool ways.Aluminium Bronze Ingots & Castings are cast as per 2 grades namely AB-1 & AB -2. The chemical compositions of the 2 grades of the alloy are tabulated below: -

Constituent	Grade AB -1	Grade AB – 2
Aluminium	8.5 – 10.5	8.8-10.0
Iron	1.5-3.5	4.0-5.5
Manganese	1.0 Max	1.5 Max
Nickel	1.0 Max	4.0-5.5
Zinc	0.50 Max	0.50 Max
Tin	0.10 Max	0.1 Max
Lead	0.05 Max	0.05 Max
Silicon	0.25 Max	0.10 Max
Magnesium	0.05 Max	0.05 Max
Total of Sn, Pb, Si & Mg	0.30 Max	0.30 Max
Copper	Remainder	Remainder
