Product Details
Leaded Tin Bronze Alloys are cast as per IS:318-1981 Reaffirmed 2006 specification. This specification covers 6 Grades of Leaded Tin Bronze Alloys for Ingots & Castings. Castings done by us are Bushings, Rods, Flanges & Castings as per drawings & dimensions. The Ingots formed are of uniform quality and reasonably free from slag, dross and other harmful contaminations. The Castings formed are clean & free from harmful defects, blowholes, gas cavities etc. The chemical composition for the Five Grades is tabulated as under: -
|
Constituent |
LTB -1 |
LTB-2 |
LTB-3 |
LTB-4 |
LTB-5 |
LTB-6 |
|
Tin |
6.0-8.0 |
4.0-6.0 |
6.0-8.0 |
6.0-8.0 |
9.0-11.0 |
4.0-6.0 |
|
Zinc |
1.5-3.0 |
4.0-6.0 |
0.75 Max |
0.75 Max |
1.0 Max |
1.0 Max |
|
Lead |
2.5-3.5 |
4.0-6.0 |
9.0-11.0 |
14.0-16.0 |
8.5-11.0 |
18.0-23.0 |
|
Nickel |
2.0 Max |
2.0 Max |
2.0 Max |
2.0 Max |
2.0 Max |
2.0 Max |
|
Aluminium |
0.01 Max |
0.01 Max |
0.01 Max |
------- |
0.01 Max |
---------- |
|
Silicon |
0.01 Max |
0.02 Max |
0.02 Max |
0.02 Max |
0.02 Max |
0.01 Max |
|
Antimony |
0.3 Max |
0.4 Max |
0.5 Max |
0.5 Max |
0.5 Max |
0.5 Max |
|
Iron |
0.30 Max |
0.35 Max |
0.35 Max |
0.35 Max |
0.35 Max |
0.35 Max |
|
Total of all Impurities |
0.70 Max, (Excluding Nickel) |
0.80 Max, (Excluding Nickel) |
0.80 Max (Excluding Nickel + Zinc) |
0.80 Max, (Excluding Nickel + Zinc) |
0.80 Max (Excluding Nickel + Zinc) |
0.80 Max (Excluding Nickel + Zinc) |
Grade LTB 1 & LTB 2 are meant for general castings and have fair strength and good machining properties. They are used in Valve fittings & pump castings. Grade LTB 3 is suitable for High speed & heavy pressure bearings. Grade LTB 4 is used for General Castings in moderate pressure applications and general-purpose bearing metal. Grade LTB 5 is used for hard or moderately hard shafts with loads and speeds moderate or low with rather less adequate lubrication and alignment. Grade LTB 6 is used for bearing under light loads and high Speeds.
